一.執行標準

1、 Execution standards

K KX-FPFP -2*2*1.0補償導線按照GB/T4989標準制造。補償電纜按照JB/T7495標準制造。

The K KX-FPFPFP-2 * 2 * 1.0 compensation wire is manufactured according to the GB/T4989 standard. The compensating cable is manufactured according to JB/T7495 standard.

阻燃及耐火特性符合GB/T19666-2005標準規定。

The flame retardant and fire-resistant properties comply with the GB/T19666-2005 standard.

二.適用范圍

2、 Scope of application

KX-FPFP -2*2*1.0補償導線廣泛適用于冶金、化工、石油、發電以及科研等部門采用熱電偶方法測量溫度的場合。用于熱電偶與測溫顯示儀表之間的連接。

KX-FPFPFP-2 * 2 * 1.0 compensation wire is widely used in metallurgy, chemical, petroleum, power generation, and scientific research departments to measure temperature using thermocouple methods. Used for connecting thermocouples and temperature display instruments.

三.型號、名稱、分度號及配套用熱電偶類型

3、 Model, name, graduation number, and matching thermocouple type

KX-FF 氟塑料絕緣氟塑料護套普通級K分度熱電偶用補償電纜

KX-FF Fluoroplastic Insulated Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FPF 氟塑料絕緣氟塑料護套銅絲編織分屏蔽普通級K分度熱電偶用補償電纜

KX-FPF fluoroplastic insulated fluoroplastic sheathed copper wire braided shielded compensating cable for ordinary grade K-index thermocouples

KX-FPFP 氟塑料絕緣氟塑料護套銅絲編織分屏蔽及總屏蔽普通級K分度熱電偶用補償電纜

KX-FPFP Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Partial Shielding and Total Shielding Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FFP 氟塑料絕緣氟塑料護套銅絲編織總屏蔽普通級K分度熱電偶用補償電纜

KX-FFP fluoroplastic insulated fluoroplastic sheathed copper wire braided total shielding compensation cable for ordinary grade K-index thermocouples

KXS-FF 氟塑料絕緣氟塑料護套精密級K分度熱電偶用補償電纜

KXS-FF Fluoroplastic Insulation Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

KXS-FPF 氟塑料絕緣氟塑料護套銅絲編織分屏蔽精密級K分度熱電偶用補償電纜

KXS-FPF Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Shielding Precision Grade K Index Thermocouple Compensation Cable

KXS-FPFP 氟塑料絕緣氟塑料護套銅絲編織分屏蔽及總屏蔽精密級K分度熱電偶用補償電纜

KXS-FPFP Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Partial Shielding and Total Shielding Compensation Cable for Precision Grade K Index Thermocouples

KXS-FFP 氟塑料絕緣氟塑料護套銅絲編織總屏蔽精密級K分度熱電偶用補償電纜

KXS-FFP Fluoroplastic Insulation Fluoroplastic Sheath Copper Wire Braided Total Shielding Precision Grade K-Scale Thermocouple Compensation Cable

KX-FP3F 氟塑料絕緣鋁/塑復合帶分屏蔽氟塑料護套普通級K分度熱電偶用補償電纜

KX-FP3F Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielded Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FP3FP3 氟塑料絕緣鋁/塑復合帶分屏蔽及總屏蔽氟塑料護套普通級K分度熱電偶用補償電纜

KX-FP3FP3 Fluoroplastic Insulated Aluminum/Plastic Composite Strip with Partial Shielding and Total Shielding Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FFP3 氟塑料絕緣氟塑料護套銅絲編織鋁/塑復合帶總屏蔽普通級K分度熱電偶用補償電纜

KX-FFP3 Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Aluminum/Plastic Composite Strip Total Shielding Compensation Cable for Ordinary Grade K-Scale Thermocouples

KXS-FP3F 氟塑料絕緣鋁/塑復合帶分屏蔽氟塑料護套精密級K分度熱電偶用補償電纜

KXS-FP3F Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielded Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

KXS-FFP3 氟塑料絕緣及護套鋁/塑復合帶總屏蔽精密級K分度熱電偶用補償電纜

KXS-FFP3 Fluoroplastic Insulation and Sheath Aluminum/Plastic Composite Strip Total Shielding Precision Grade K Index Thermocouple Compensation Cable

KXS-FP3FP3 氟塑料絕緣鋁/塑復合帶分屏蔽及總屏蔽氟塑料護套精密級K分度熱電偶用補償電纜

KXS-FP3FP3 Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielding and Total Shielding Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

注：

Note:

1、其它型號補償電纜EX、SC、KC、NC、NX、BC、TX、JX，只需改寫型號的第一項，如EX-FF EX-FPF等。

1. Other models of compensating cables EX SC、KC、NC、NX、BC、TX、JX， Just rewrite the first item of the model, such as EX-FF EX-FPF, etc.

2、對于銅帶屏蔽的電纜只需將型號中的P3改寫成P2即可，如KX-FP2F即是氟塑料絕緣銅帶繞包分屏蔽氟塑料護套普通級K分度熱電偶用補償電纜。

2. For copper tape shielded cables, simply rewrite P3 in the model to P2. For example, KX-FP2F is a compensating cable for fluoroplastic insulated copper tape wrapped and shielded fluoroplastic sheathed ordinary grade K-index thermocouples.

3、還有一些特制的聚四氟乙烯薄膜與玻璃絲復合絕緣及護套的高溫補償電纜，如：KXHF4

3. There are also some special high-temperature compensation cables with composite insulation and sheath of polytetrafluoroethylene film and glass fiber, such as KXHF4

表1

Table 1

型號	名稱	分度號	配套用熱電偶類型	絕緣層顏色
				正極	負極
SC	銅－銅鎳0.6補償型電纜	S	鉑銠10－鉑熱電偶	紅	綠
RC	銅－銅鎳0.6補償型電纜	R	鉑銠13－鉑熱電偶	紅	綠
KCA	鐵－銅鎳22補償型電纜	K	鎳鉻－鎳硅熱電偶	紅	藍
KCB	銅－銅鎳40補償型電纜			紅	藍
KX	鎳鉻10－鎳硅3延長型電纜			紅	黑
NC	鐵－銅鎳18補償型電纜	N	鎳鉻硅－鎳硅熱電偶	紅	灰
NX	鎳鉻14硅－鎳硅延長型電纜			紅	灰
EX	鎳鉻10－鎳硅45延長型電纜	E	鎳鉻－銅鎳熱電偶	紅	棕
JX	鐵－銅鎳45補償型電纜	J	鐵－銅鎳熱電偶	紅	紫
TX	銅－銅鎳45補償型電纜	T	銅－銅鎳熱電偶	紅	白
