產品名稱：High temperature compensation wireZR-KX-HA-FFP
瀏覽：
添加時間：2024-07-26 15:27:49
推薦度：

介紹：

一：產品特點及用途

1： Product Features and Applications

　　一般用聚氯乙烯絕緣和護套補償導線或電纜具有優良的防潮、耐磨及阻燃特性；耐高溫氟塑料絕緣和護套補償導線或電纜采用連續擠出工藝，更有耐高溫、耐寒、耐酸堿油水、不延燃、***等優越性

Generally, PVC insulated and sheathed compensating wires or cables have excellent moisture-proof, wear-resistant, and flame-retardant properties; High temperature resistant fluoroplastic insulation and sheath compensation wires or cables adopt continuous extrusion technology, which has advantages such as high temperature resistance, cold resistance, acid alkali oil-water resistance, non flame retardant

二：產品執行標準

2： Product execution standards

GB/T4989-94（等效采用IEC584-3標準）

GB/T4989-94 (equivalent to IEC584-3 standard)

三：使用特性

3： Usage characteristics

1．導體工作溫度：耐熱級：聚全氟乙丙烯（F46）200℃

1. Conductor operating temperature: Heat resistance grade: Perfluoroethylene propylene (F46) 200 ℃

可溶性聚四氟乙烯260℃

Soluble polytetrafluoroethylene 260 ℃

硅橡膠180℃

Silicone rubber at 180 ℃

普通級：聚氯乙烯70℃和105℃，交聯聚乙烯90℃

Ordinary grade: polyvinyl chloride at 70 ℃ and 105 ℃, cross-linked polyethylene at 90 ℃

低煙無鹵阻燃聚烯烴70℃，交聯型90℃和125℃

Low smoke halogen-free flame-retardant polyolefin at 70 ℃, cross-linked at 90 ℃ and 125 ℃

2．低環境溫度：聚氯乙烯護套：固定敷設-40℃，非固定敷設-15℃

2. Low ambient temperature: PVC sheath: fixed installation -40 ℃, non fixed installation -15 ℃

氟塑料絕緣和護套：固定敷設-60℃，非固定敷設-20℃

Fluoroplastic insulation and sheath: fixed installation -60 ℃, non fixed installation -20 ℃

3．電纜允許彎曲半徑：非鎧裝電纜***小為外徑的6倍

3. Allowable bending radius for cables: The minimum allowable bending radius for non armored cables is 6 times the outer diameter

銅帶屏蔽或鋼帶鎧裝點纜***小為電纜外徑的12倍

Copper tape shielded or steel tape armored point cables shall have a minimum diameter of 12 times the outer diameter of the cable

氟塑料絕緣和護套***小為電纜外徑的10倍

Fluoroplastic insulation and sheath with a minimum of 10 times the outer diameter of the cable

四：基本型號及名稱

4： Basic model and name

KX-GA-VV

聚氯乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償導線

PVC insulated PVC sheathed precision grade K division thermocouple compensation wire

KX-GA-VVR

聚氯乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償軟導線

PVC insulated PVC sheathed precision grade K division thermocouple compensation flexible wire

KX-GA-VVP

聚氯乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

PVC insulated PVC sheathed copper wire braided shielding precision grade K division thermocouple compensation wire

KX-GA-VVRP

聚氯乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線

PVC insulated PVC sheathed copper wire braided shielding precision grade K division thermocouple compensation flexible wire

KX-HA-FF

氟塑料絕緣和護套精密級K分度號熱電偶補償導線

Fluoroplastic insulation and sheath precision grade K division thermocouple compensation wire

KX-HA-FFR

氟塑料絕緣和護套精密級K分度號熱電偶補償軟導線

Fluoroplastic insulation and sheath precision grade K division thermocouple compensation flexible wire

KX-HA-FFP

氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

Fluoroplastic insulated and sheathed copper wire braided shielding precision grade K division thermocouple compensation wire

KX-HA-FFRP

氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線

Fluoroplastic insulated and sheathed copper wire braided shielding precision grade K division thermocouple compensation flexible wire

KX-HA-FG

氟塑料絕緣硅橡膠護套精密級K分度號熱電偶補償導線

Fluoroplastic insulated silicone rubber sheathed precision grade K division thermocouple compensation wire

KX-HA-FGR

氟塑料絕緣硅橡膠護套精密級K分度號熱電偶補償軟導線

Fluoroplastic insulated silicone rubber sheath precision grade K division thermocouple compensation flexible wire

KX-HA-FGP

氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

Fluoroplastic insulation, silicone rubber sheath, copper wire braided shielding, precision grade K division thermocouple compensation wire

KX-HA-FGRP

氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線

Fluoroplastic insulation, silicone rubber sheath, copper wire braided shielding, precision grade K division thermocouple compensation flexible wire

KX-HA-FV

氟塑料絕緣聚氯乙烯護套精密級K分度號熱電偶補償導線

Fluoroplastic insulated PVC sheathed precision grade K division thermocouple compensation wire

KX-HA-FVR

氟塑料絕緣聚氯乙烯護套精密級K分度號熱電偶補償軟導線

Fluoroplastic insulated PVC sheathed precision grade K division thermocouple compensation flexible wire

KX-HA-FVP

氟塑料絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

Fluoroplastic insulated PVC sheathed copper wire braided shielding precision grade K division thermocouple compensation wire

KX-HA-FVRP

氟塑料絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線

Fluoroplastic insulated PVC sheathed copper wire braided shielding precision grade K division thermocouple compensation flexible wire

KX-GA-YJV

交聯聚乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償導線

Cross linked polyethylene insulated polyvinyl chloride sheathed precision grade K division thermocouple compensation wire

KX-GA-YJVR

交聯聚乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償軟導線

Cross linked polyethylene insulated polyvinyl chloride sheathed precision grade K division thermocouple compensation flexible wire

KX-GA-YJVP

交聯聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

Cross linked polyethylene insulation, polyvinyl chloride sheath, copper wire braided shielding, precision grade K division thermocouple compensation wire

KX-GA-YJVRP

低煙無鹵絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線

Low smoke halogen-free insulated and sheathed copper wire braided shielding precision grade K division thermocouple compensation flexible wire

KX-GA-YDYD

低煙無鹵絕緣和護套精密級K分度號熱電偶補償導線

Low smoke halogen-free insulation and sheath precision grade K division thermocouple compensation wire

KX-GA- YDYD R

低煙無鹵絕緣和護套精密級K分度號熱電偶補償軟導線

Low smoke halogen-free insulation and sheath precision grade K division thermocouple compensation flexible wire

KX-GA- YDYD P

低煙無鹵絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償導線

Low smoke halogen-free insulated and sheathed copper wire braided shielding precision grade K division thermocouple compensation wire
