- 產(chǎn)品名稱：Motor winding wire motor lead wire JBQ
- 瀏覽：
- 添加時間：2025-04-07 16:31:49
- 推薦度：
一、執(zhí)行標準：JBQ電機用電纜JBQ引出線單芯電纜
1、 Execution standard: JBQ motor cable, JBQ lead out single core cable
JB6213 92 Q／12YJ 4135-2000
JB6213 92 Q／12YJ 4135-2000
二、適用范圍：
2、 Scope of application:
適用于交流額定電壓6000V及以下的電機繞組的引出連接用。
Suitable for the lead out connection of motor windings with AC rated voltage of 6000V and below.
三、使用特性：JBQ電機用電纜JBQ引出線單芯電纜
3、 Usage characteristics: JBQ motor cable, JBQ lead out single core cable
電線導體的長期允許工作溫度應不超過70℃。具有良好的柔軟性及耐熱、耐溶劑性。
The long-term allowable working temperature of wire conductors should not exceed 70 ℃. Has good flexibility, heat resistance, and solvent resistance.
四、型號和名稱：
4、 Model and Name:
JF(JBF) 銅芯聚氯乙烯復合物絕緣電機繞組引接電纜(電線)
JF (JBF) copper core polyvinyl chloride composite insulated motor winding lead cable (wire)
JV(JBV) 銅芯聚氯乙烯絕緣電機繞組引接電纜(電線)
JV (JBV) copper core PVC insulated motor winding lead cable (wire)
JXN(JBQ) 銅芯橡皮絕緣護套電機繞組引接軟電纜(電線)
JXN (JBQ) copper core rubber insulated sheathed motor winding connection flexible cable (wire)
JXF(JBHF) 銅芯橡皮絕緣氯丁護套電機繞組引接軟電纜(電線)
JXF (JBHF) copper core rubber insulated chloroprene sheathed motor winding connection flexible cable (wire)
