硅橡膠電纜的型號和技術要求

Model and technical requirements for silicone rubber cables

一：產品特點及用途:本產品適用于交流額定電壓0.6/1KV及以下固定敷設用動力傳輸線或移動電器用連接電纜，產品具有耐熱輻射、耐寒、耐酸堿及腐蝕性氣體、防水等特性，電纜結構柔軟，輻射方便，高溫(高寒)環境下電氣性能穩定，抗老化性能突出，使用壽命長，廣泛用于冶金、電力、石化、電子、汽車制造等行業。

1： Product features and uses: This product is suitable for power transmission lines for fixed laying or connecting cables for mobile appliances with AC rated voltage of 0.6/1KV and below. The product has the characteristics of heat radiation resistance, cold resistance, acid and alkali resistance, corrosive gas resistance, waterproof, etc. The cable structure is soft, radiation is convenient, electrical performance is stable under high temperature (high cold) environment, anti-aging performance is outstanding, and service life is long. It is widely used in metallurgy, power, petrochemical, electronics, automobile manufacturing and other industries.

二：產品執行標準

2： Product execution standards

Q/HL005-2002.1

Q/HL005-2002.1

阻燃耐火特性試驗執行GB12666-90要求

The flame retardant and fire-resistant characteristics test shall comply with the requirements of GB12666-90

三：使用特性

3： Usage characteristics

1． 交流額定電壓：U0/U 0.6/1KV

1. Rated AC voltage: U0/U 0.6/1KV

***高工作溫度： 180℃

Maximum operating temperature: 180℃

***低環境溫度：固定敷設-60℃

Minimum ambient temperature: Fixed installation -60 ℃

2． 電纜安裝敷設溫度應不低于-25℃。

2. The temperature for cable installation and laying should not be lower than -25 ℃.

3． 電纜允許彎曲半徑：電纜***小為電纜外徑的10

3. Allowable bending radius for cables: The minimum allowable bending radius for cables is 10 times the outer diameter of the cable

4。 電纜品名：硅橡膠電力電纜、硅橡膠控制電纜、硅橡膠屏蔽電纜、硅橡膠耐油電纜、硅橡膠電機引接線、硅橡膠高溫電纜、阻燃硅橡膠電纜、硅橡膠控制電纜、硅橡膠扁平電纜、硅橡膠移動電纜、硅橡膠高壓電纜、硅橡膠軟電纜、鍍錫硅橡膠屏蔽電纜、鍍錫硅橡膠軟電纜。

4. Cable Product Name: Silicone Rubber Power Cable, Silicone Rubber Control Cable, Silicone Rubber Shielded Cable, Silicone Rubber Oil Resistant Cable, Silicone Rubber Motor Lead Wire, Silicone Rubber High Temperature Cable, Flame Retardant Silicone Rubber Cable, Silicone Rubber Control Cable, Silicone Rubber Flat Cable, Silicone Rubber Mobile Cable, Silicone Rubber High Voltage Cable, Silicone Rubber Flexible Cable, Tin Plated Silicone Rubber Shielded Cable, Tin Plated Silicone Rubber Flexible Cable.

5. 電纜型號Cable type：AGR、KGG、YGC、YGG、JGG、KFG、JFG、YFG、FGR、GGR、GGRP、GGPR、FGPR、AGGPR、KGGPR、YGCPR、YGGPR、DJFPGP22、ZR-DJFP2GP2/22、JFPGP22JFP2GP2/22、DJFPGPR22、DJGGPR22、DJFGPR22、DJGPGR22、DJFPGR22、DJGPGRP22、JFGRP22、DJGPVFP、DJGPVFR、DJGPVFPR、DJGVFP、KGVF、KGVFR、KGVFP、KGVFRP、ZR-KGVF、ZR-KGVFP、ZR-KGVFPR、DJGP2VFP2、DJGP2VFR、DJGP2VFPR、DJGVFP2、ZR-JGPVFP、ZR-JGPVFR、ZR-JGPVFPR、ZR-JGVFP、ZR-KGGRB、ZR-YGGRB、ZR-YGCRB、ZR-JGGRB、ZR-YFGRB、ZR-KFGRB、ZR-YFGRB、ZA-DJFPGP、ZA-DJGGR、ZA-DJGGP、ZA-DJGGP2、ZA-DJFP2GP2、ZA-DJFPGPR、ZA=DJGGPR、ZA-DJFGPR、ZA-DJGPGR、ZA-DJFPGR、ZA-DJGPGRP、ZA-DJFPGRP、ZA-DJFPGP22、ZA-DJFP2GP2/22
