- 產品名稱：ZR-KFFP Fluoroplastic High Temperature Cable
- 瀏覽：
- 添加時間：2025-04-10 15:15:32
- 推薦度：
用于用電設備器具的控制接線路，長期工作溫度為200℃，彎曲半徑不小于電纜外徑的8倍，有鎧裝或屏蔽的電纜應不小于電纜外徑的15倍。適用于工礦企業、能源*門、供交流額定電壓450/750伏以下控制、保護線路等高溫場合使用的氟塑料絕緣、氟塑料護套控制電纜。
Control wiring for electrical equipment and appliances, with a long-term operating temperature of 200 ℃ and a bending radius not less than 8 times the outer diameter of the cable. For armored or shielded cables, the bending radius should not be less than 15 times the outer diameter of the cable. Fluoroplastic insulated and fluoroplastic sheathed control cables suitable for high temperature applications such as industrial and mining enterprises, energy gates, and control and protection circuits with AC rated voltage below 450/750 volts.
P1鍍錫絲屏蔽、P2銅帶屏蔽、P3鋁/塑復合薄膜屏蔽、9鋼絲編織鎧裝
P1 tin plated wire shielding, P2 copper tape shielding, P3 aluminum/plastic composite film shielding, 9 steel wire braided armor
舉例：銅芯氟塑料絕緣氟塑料護套銅絲屏蔽控制軟電纜，移動敷設用，額定電壓450/750V、19芯、1.5mm2表示為：
Example: Copper core fluoroplastic insulated fluoroplastic sheathed copper wire shielded control flexible cable, for mobile installation, rated voltage 450/750V, 19 cores, 1.5mm2 expressed as:
KFFRP-450/750V 19*1.5mm2
KFFRP-450/750V 19*1.5mm2
銅芯氟塑料絕緣氟塑料護套控制電纜，固定敷設用，額定電壓450/750V、7芯、1.5mm2表示為：
Copper core fluoroplastic insulated fluoroplastic sheathed control cable, for fixed installation, rated voltage 450/750V, 7-core, 1.5mm2 expressed as:
KFF-450/750V 7*1.5mm2
KFF-450/750V 7*1.5mm2
型號model | 導體標稱截面Nominal cross-section of conductor mm2 | |||||
0.5 | 0.75 | 1.0 | 1.5 | 2.5 | 4 | 6 |
芯數 CORE | ||||||
KFF KFFP | - | 2-19 | 2-12 | |||
KFFP2 | - | 2-19 | 2-12 | |||
KFFR | 2-19 | 2-12 | ||||
KFFRP | 2-19 | 2-12 | ||||
KFF9F | - | 2-19 | 2-12 | |||
注：推薦的芯數系列為Note: The recommended chip count series is：2、3、4、5、7、8、10、12、14、16、19芯 |
