產品名稱：high temperature and fire-resistant cablesABHBR
瀏覽：
添加時間：2025-04-29 13:53:17
推薦度：
介紹：
ABHBR,ABHBRP耐高溫防火電纜 ABHBR, ABHBRP high temperature and fire-resistant cables 一：產品特點及用途 1： Product Features and Applications ABHBR,ABHBRP電纜適用于發電、冶金等高溫、防火、防腐等惡劣環境下移動電器用電氣連接或動力傳輸。 ABHBR and ABHBRP cables are suitable for electrical connections or power transmission of mobile electrical appliances in harsh environments such as power generation, metallurgy, high temperature, fire prevention, and corrosion prevention. 二：產品執行標準 2： Product execution standards Q/HHTZH009.3 Q/HHTZH009.3 耐火特性符合GB12666.6-90要求(IEC331) Fire resistance characteristics meet the requirements of GB12666.6-90 (IEC331) 三：使用特性 安徽中盛電氣集團有限公司（Anhui Zhongsheng Electric Group Co., Ltd） 3： Usage characteristics 1． 交流額定電壓： 1KV及以下 1. Rated AC voltage: 1KV and below ***高使用溫度：一種-40-500℃ Maximum operating temperature: -40-500 ℃ 一種-40-800℃ A temperature range of -40-800 ℃ 2． 耐火特性：火焰溫度950-1000℃、燃燒時間90min、附加額定電壓3A電流 2. Fire resistance characteristics: flame temperature 950-1000 ℃, combustion time 90min, additional rated voltage 3A current 四：耐高溫防火電纜型號及名稱 安徽中盛電氣集團有限公司（Anhui Zhongsheng Electric Group Co., Ltd） 4： Model and name of high-temperature resistant and fire-resistant cable
型號Model
產品名稱product name
ABHBR
耐高溫防火軟電纜High temperature resistant and fire-resistant flexible cable
ABHBRP
耐高溫屏蔽防火軟電纜High temperature resistant shielded fireproof flexible cable
備注：阻燃聚氯乙烯護套型號前加ZR，鎧裝電纜型號后加22Note: ZR should be added before the flame-retardant PVC sheath model, and 22 should be added after the armored cable model 安徽中盛電氣集團有限公司（Anhui Zhongsheng Electric Group Co., Ltd）
五：主要技術指標Specification
性能項目Performance project
單位unit
技術指標TECHNICAL INDEX
20℃導體直流電阻Direct current resistance of conductor≤
Ω/km
參照表reference table
試驗電壓 testing voltage
3.5/5min
絕緣電阻 insulation resistance
MΩ/km
500
耐火特性Fire resistance characteristics
GB12666.6A類或B類Class 6A or Class B
阻燃特性Flame retardant properties
GB12666.5A類或B類Class 5A or Class B
六：基本電纜規格及結構參數Basic cable specifications and structural parameters 安徽中盛電氣集團有限公司（Anhui Zhongsheng Electric Group Co., Ltd）
