• 產品名稱：WFYS-YJY anti ant and rodent power cable
• 瀏覽：
• 添加時間：2025-04-29 14:14:47
• 推薦度：
•

防蟻鼠電力電纜

Anti ant and rodent power cable

　　一、產品特點及用途

1、 Product Features and Applications

　　本產品適用于在蟻鼠危害比較嚴重，且有綠色環保要求的場所，特別是埋地和管道敷設的電力系統輸配線路。具有以下幾點特點：

This product is suitable for places with serious ant and rodent hazards and green environmental protection requirements, especially for buried and pipeline laid power system transmission and distribution lines. Has the following characteristics:

　　1、產品能有效預防白蟻、鼠類對電纜的危害，性能可靠長久，無需其他輔助方法；

1. The product can effectively prevent the harm of termites and rodents to cables, with reliable and long-lasting performance, without the need for other auxiliary methods;

　　2、電纜產品內無對空氣、土壤、人身造成污染和危害的材料，屬綠色環保型產品；

2. The cable product contains no materials that cause pollution or harm to the air, soil, or human body, and is considered a green and environmentally friendly product;

　　3、五芯電力電纜適用于三相五線制輸配電系統，由于中性線與地線分開使得系統運行更加穩定，操作人員更為安全。且五芯電力電纜采用獨特的瓦形設計，使電纜具有結構穩定、重量輕、外徑小的特點。

3. Five core power cables are suitable for three-phase five wire transmission and distribution systems. Due to the separation of neutral and ground wires, the system operates more stably and operators are safer. And the five core power cable adopts a unique tile shaped design, which makes the cable structurally stable, lightweight, and has a small outer diameter.

　　二、產品執行標準

2、 Product execution standards

　　Q/AT2003-4

Q/AT2003-4

　　三、基本型號及名稱

3、 Basic model and name

型號 名稱

Model name

銅芯Cu 鋁芯AL

Copper core, Cu aluminum core, AL

WFYS-YJY WFYS-YJLY 銅芯(鋁芯)交聯聚乙烯絕緣無毒無害防蟻鼠聚烯烴護套電力電纜

WFYS-YJY WFYS-YJLY Copper (Aluminum) Cross linked Polyethylene Insulated Non toxic, Harmless, Ant proof, Mouse proof Polyolefin Sheathed Power Cable

WFYS-YJY23 WFYS-YJLY23 銅芯(鋁芯)交聯聚乙烯絕緣鋼帶鎧裝無毒無害防蟻鼠聚烯烴護套電力電纜

WFYS-YJY23 WFYS-YJLY23 Copper Core (Aluminum Core) Cross linked Polyethylene Insulated Steel Strip Armored Non toxic, Harmless, Ant proof, Rat proof Polyolefin Sheathed Power Cable

WFYS-YJY33 WFYS-YJLY33 銅芯(鋁芯)交聯聚乙烯絕緣細鋼絲鎧裝無毒無害防蟻鼠聚烯烴護套電力電纜

WFYS-YJY33 WFYS-YJLY33 copper core (aluminum core) cross-linked polyethylene insulated fine steel wire armored non-toxic and harmless ant and rodent proof polyolefin sheathed power cable

WFYS-YJY43 WFYS-YJLY43 銅芯(鋁芯)交聯聚乙烯絕緣粗鋼絲鎧裝無毒無害防蟻鼠聚烯烴護套電力電纜

WFYS-YJY43 WFYS-YJLY43 Copper core (aluminum core) cross-linked polyethylene insulated thick steel wire armored non-toxic and harmless ant and rodent proof polyolefin sheathed power cable

WFYS-YJY53 WFYS-YJLY53 銅芯(鋁芯)交聯聚乙烯絕緣軋紋鋼帶鎧裝無毒無害防蟻鼠聚烯烴護套電力電纜

WFYS-YJY53 WFYS-YJLY53 copper core (aluminum core) cross-linked polyethylene insulated corrugated steel tape armored non-toxic and harmless ant and rodent proof polyolefin sheathed power cable

　　四、主要技術參數

4、 Main technical parameters

　　1、 成品電纜經受交流50HZ、5min、3500V的電壓試驗不擊穿，對于單芯非鎧裝電纜，則進行浸水耐壓試驗；

1. Finished cables shall withstand AC 50HZ, 5-minute, 3500V voltage test without breakdown. For single core non armored cables, immersion withstand voltage test shall be conducted;

　　2、 90℃絕緣電阻常數不小于3.67MΩ/KM；

2. The insulation resistance constant at 90 ℃ shall not be less than 3.67M Ω/KM;

　　3、 電纜防蟻鼠性能符合GB/T2951.38《電線電纜蟻鼠試驗方法》中2.2“實驗群體法”的規定。

3. The anti ant and rodent performance of cables complies with the provisions of section 2.2 "Experimental Group Method" in GB/T2951.38 "Test Methods for Ants and Rodents in Wires and Cables".

　　五、電纜規格

5、 Cable specifications
