產品名稱：Generator rotor high-voltage insulated cable WDZ-YJGFP22
瀏覽：
添加時間：2025-05-07 10:22:15
推薦度：

介紹：

一：電纜型號規格結構

1： Cable model, specification, and structure

型號規格WDZ-YJGFP22-3KV 4x4 ；優質純銅導體，絕緣采用合成耐高壓新型材料，銅絲編織屏蔽，鎧裝，

Model and specification WDZ-YJGFP22-3KV 4x4; High quality pure copper conductor, insulated with synthetic high-voltage resistant new materials, copper wire braided shielding, armor,

護套使用阻燃合成高性能新型材料，電纜具有阻燃防老化，耐高壓使用壽命長等特點。

The sheath is made of flame-retardant synthetic high-performance new materials, and the cable has the characteristics of flame retardancy, anti-aging, high voltage resistance, and long service life.

二：產品特點及用途

2： Product Features and Applications

本產品適用于交流額定電壓3KV動力裝置及電力線路中傳輸用，高絕緣電纜具有**的耐熱機械性能，優異的電氣性能和耐化學腐蝕性能等優點，因此廣泛應用于電力、石化、冶金等企業。

This product is suitable for transmission in AC rated voltage 3KV power devices and power lines. High insulation cables have the advantages of * * heat-resistant mechanical performance, excellent electrical performance, and chemical corrosion resistance. Therefore, they are widely used in power, petrochemical, metallurgical and other enterprises.

低煙無鹵電纜基本型號及名稱

Basic models and names of low smoke halogen-free cables

型號名稱

Model name

DLD-KVV 銅芯低煙低鹵聚氯乙烯絕緣和護套控制電纜

DLD-KVV copper core low smoke and low halogen polyvinyl chloride insulated and sheathed control cable

DLD-KVVP 銅芯低煙低鹵聚氯乙烯絕緣和護套銅網編織屏蔽控制電纜

DLD-KVVP copper core low smoke and low halogen polyvinyl chloride insulated and sheathed copper mesh braided shielded control cable

DLD-KVV22 銅芯低煙低鹵聚氯乙烯絕緣和護套鋼帶鎧裝控制電纜

DLD-KVV22 copper core low smoke and low halogen polyvinyl chloride insulated and sheathed steel tape armored control cable

WLD-KJEG 銅芯無鹵低煙交聯聚烯烴絕緣熱固性護套控制電纜

WLD-KJEG Copper Core Halogen Free Low Smoke Cross linked Polyolefin Insulated Thermosetting Sheath Control Cable

WLD-KJEGP 銅芯無鹵低煙交聯聚烯烴絕緣熱固性護套銅網屏蔽控制電纜

WLD-KJEGP copper core halogen-free low smoke cross-linked polyolefin insulated thermosetting sheathed copper mesh shielded control cable

WLD-KJEGP2-22 銅芯無鹵低煙交聯聚烯烴絕緣熱固性護套銅帶屏蔽鋼帶鎧裝控制電纜

WLD-KJEGP2-22 copper core halogen-free low smoke cross-linked polyolefin insulation thermosetting sheath copper tape shielding steel tape armored control cable

WLD-KJES 銅芯無鹵低煙交聯聚烯烴絕緣熱塑性護套控制電纜

WLD-KJES copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed control cable

WLD-KJESP 銅芯無鹵低煙交聯聚烯烴絕緣熱塑性護套銅網屏蔽控制電纜

WLD-KJESP copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed copper mesh shielded control cable

WLD-KJES22 銅芯無鹵低煙交聯聚烯烴絕緣熱塑性護套鋼帶鎧裝控制電纜

WLD-KJES22 copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed steel tape armored control cable

DLD-KSF 銅芯低煙低鹵熱塑性絕緣熱塑體護套控制電纜

DLD-KSF copper core low smoke and low halogen thermoplastic insulated thermoplastic sheathed control cable

DLD-KSFP 銅芯低煙低鹵熱塑性絕緣熱塑體護套銅網屏蔽控制電纜

DLD-KSFP copper core low smoke and low halogen thermoplastic insulated thermoplastic sheathed copper mesh shielded control cable

DLD-KSFP2-22 銅芯低煙低鹵熱塑性絕緣熱塑體護套銅帶屏蔽鋼帶鎧裝控制電纜

DLD-KSFP2-22 Copper Core Low Smoke and Low Halogen Thermoplastic Insulation Thermoplastic Sheath Copper Tape Shielding Steel Tape Armored Control Cable

低煙無鹵電纜型號代號、名稱及含義

Low smoke halogen-free cable model code, name and meaning

項目代號含義

Meaning of project code

系列代號 DLD

Series code DLD

WLD

K 低煙低鹵

K low smoke and low halogen

低煙無鹵

LSZH

控制電纜
